Can be applied over solvent-based basecoats and properly prepared paintwork in good condition.
Mixing Ratio
2 parts clearcoat, 1 part hardener, plus 10–20% thinner.
Pot Life
3 hours at 23°C after mixing with hardener.
Spray Gun Tips
Nozzle: 1.3 mm
Conventional: 3.0–3.5 bar (45–50 psi)
HVLP: 2 bar (26–30 psi)
Spray Method
Application viscosity: 16–18 seconds (DIN Cup 4 at 23°C)
Apply 2 to 3 coats, total film thickness of 40–60 μm
Flash-off time between coats: 5–10 minutes at 23°C
Drying Time
At 15°C, the surface is dust-free in 50 minutes and polishable in 12 hours.
At 23°C, it is dust-free in 30–40 minutes and polishable in 6–8 hours.
At 60°C, it is dust-free in 10 minutes and polishable in 30 minutes.
Shelf Life
2 years in unopened containers when stored in cool, dry conditions.
Health and Safety
Refer to the Material Safety Data Sheet (MSDS) for full safety guidance.
Follow all precautionary instructions on the container.
Ensure proper ventilation in the working environment.
*High gloss.
*Excellent durability.
*Scratch resistant with high UV protection.
*Yellowing resistant.
Mixing ratio:
Clearcoat: 2 parts.
Hardener: 1 part.
Thinner: 0.2-0.5 parts.
Pot life:
4 hours @25℃.
Spray gun & air pressure:
Gravity type: 1.2-1.4mm.
Suction type: 1.3-1.5mm.
Spray method:
Spray 2-3 layers, the volatilization time of each layer is 5 to 10 minutes.
Drying time:
Temperature | Dust free | Drying time for touch | Complete drying time |
20℃ | 30 minutes | 2 hours | 12 hours |
60℃ | 10 minutes | 20 minutes | 50 minutes |
*Perfect gloss.
*Excellent durability.
*Scratch resistant with high UV protection.
*Yellowing resistant.
Mixing ratio:
Clearcoat: 2 parts.
Hardener: 1 part.
Thinner: 0.2-0.5 parts.
Pot life:
4 hours @25℃.
Spray gun & air pressure:
Gravity type: 1.2-1.4mm.
Suction type: 1.3-1.5mm.
Spray method:
Spray 2-3 layers, the volatilization time of each layer is 5 to 10 minutes.
Drying time:
Temperature | Dust free | Drying time for touch | Complete drying time |
20℃ | 30 minutes | 2 hours | 12 hours |
60℃ | 10 minutes | 20 minutes | 50 minutes |
Substrates
Can be applied over solvent-based basecoats and properly prepared paint surfaces in good condition.
Mixing Ratio
2 parts clearcoat to 1 part hardener.
Pot Life
1 hour at 23°C after mixing with hardener.
Spray Gun Tips
Nozzle: 1.3 mm
Conventional: 3.0–3.5 bar (45–50 psi)
HVLP: 2 bar (26–30 psi)
Spray Method
Application viscosity: 16–18 seconds (DIN Cup 4 at 23°C)
Coats: 2 to 3 coats, total film thickness 40–60 μm
Flash-off time between coats: 3–4 minutes at 23°C
Drying Time
At 15°C, the surface is dust-free in 25 minutes and polishable in 60 minutes.
At 23°C, it is dust-free in 20 minutes and polishable in 45 minutes.
At 30°C, it is dust-free in 15 minutes and polishable in 30 minutes.
Shelf Life
2 years in unopened containers when stored in cool, dry conditions.
Health and Safety
Refer to the Material Safety Data Sheet (MSDS) for full information.
Follow all precautionary labels and instructions on the container.
Ensure good ventilation in the working area.
